Bugle head drywall screw fine thread for metal constructions

51
.
02
GUS

A drywall screw for metal profiles is a specialized fastener designed for mounting drywall to metal structures such as steel or aluminum profiles. This type of screw is essential in construction, especially in commercial and industrial projects where metal structures are commonly used.

For installation inside the building of plasterboards to metal profiles with a maximum thickness of 0.8 mm.

Intendent to use:

  • Drywall screws for metal profiles are used in the following applications:
  • Installation of Partition Walls: Used to install plasterboards on metal structures to create partition walls inside buildings.
  • Ceiling installation: Used to attach boards to metal frames of suspended ceilings.
  • Metal Structures: Perfect for attaching boards to metal structures such as steel or aluminum profiles.
  • Commercial and Industrial Projects: Often used in construction projects where metal structures are the main structural elements.

Benefits:

  • Durability: Drywall screws for metal profiles are made of durable materials that ensure long-lasting fastening.
  • Quick Installation: Thanks to the self-tapping thread, the screws can be inserted easily and quickly, which speeds up the installation process.
  • Multi-use: Suitable for various types of metal structures and construction projects.
  • Corrosion Resistance: Hardened steel or other materials used to manufacture screws are resistant to corrosion, ensuring durability in any environment.

Recommended

Group
5102

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Diameter d [mm]
Length L [mm]
Packaging type
Head diameter D [mm]
Recess
Variety of coating
Unit of measure
Availability

Step 2. Browse product variants and use additional filters

Material index
More attributes
Diameter d [mm] Length L [mm] Packaging type Head diameter D [mm] Recess Variety of coating Unit of measure Availability Show More
5102035025PHF4WO
3.5 25 Bucket 8.6 PH 2 phosphated coating BOX
5102035025PHFDXK
3.5 25 Cardboard 8.6 PH 2 phosphated coating KG
5102035025PHFK
3.5 25 Cardboard 8.6 PH 2 phosphated coating KG
5102035025PHFO
3.5 25 Cardboard 8.6 PH 2 phosphated coating BOX
5102035025PHFT
3.5 25 Bag 8.6 PH 2 phosphated coating THS
5102035025PHFTSMT
3.5 25 On the tape 8.6 PH 2 phosphated coating THS
5102035035PHF4WO
3.5 35 Bucket 8.6 PH 2 phosphated coating BOX
5102035035PHFDXK
3.5 35 Cardboard 8.6 PH 2 phosphated coating KG
5102035035PHFK
3.5 35 Cardboard 8.6 PH 2 phosphated coating KG
5102035035PHFO
3.5 35 Cardboard 8.6 PH 2 phosphated coating BOX
5102035035PHFT
3.5 35 Bag 8.6 PH 2 phosphated coating THS
5102035035PHFTSMT
3.5 35 On the tape 8.6 PH 2 phosphated coating THS
5102035045PHF3WO
3.5 45 Bucket 8.6 PH 2 phosphated coating BOX
5102035045PHFDXK
3.5 45 Cardboard 8.6 PH 2 phosphated coating KG
5102035045PHFK
3.5 45 Cardboard 8.6 PH 2 phosphated coating KG
5102035045PHFO
3.5 45 Cardboard 8.6 PH 2 phosphated coating BOX
5102035045PHFT
3.5 45 Cardboard 8.6 PH 2 phosphated coating THS
5102035055PHFDXK
3.5 55 Cardboard 8.6 PH 2 phosphated coating KG
5102035055PHFK
3.5 55 Cardboard 8.6 PH 2 phosphated coating KG
5102035055PHFO
3.5 55 Cardboard 8.6 PH 2 phosphated coating BOX
5102035055PHFT
3.5 55 Bag 8.6 PH 2 phosphated coating THS
5102039045PHFTSMT
3.5 45 On the tape 8.6 PH 2 phosphated coating THS
5102039055PHFTSMT
3.5 55 On the tape 8.6 PH 2 phosphated coating THS
5102042070PHFDXK
4.2 70 Cardboard 8.6 PH 2 phosphated coating KG
5102042070PHFDXT
4.2 70 Cardboard 8.6 PH 2 phosphated coating THS
5102042070PHFK
4.2 70 Cardboard 8.6 PH 2 phosphated coating KG
5102042070PHFO
4.2 70 Cardboard 8.6 PH 2 phosphated coating BOX
5102042070PHFT
4.2 70 Cardboard 8.6 PH 2 phosphated coating THS
5102042090PHFDXK
4.2 90 Cardboard 8.6 PH 2 phosphated coating KG
5102042090PHFK
4.2 90 Cardboard 8.6 PH 2 phosphated coating KG
5102042090PHFO
4.2 90 Cardboard 8.6 PH 2 phosphated coating BOX
5102042090PHFT
4.2 90 Cardboard 8.6 PH 2 phosphated coating THS
5102048100PHFDXK
4.8 100 Cardboard 9.2 PH 2 phosphated coating KG
5102048120PHFDXK
4.8 120 Cardboard 9.2 PH 2 phosphated coating KG
